Product Parameters
Material: ABS
Weight:225g
Size: 155*75*68mm
Compatible: XBOXONE , Xbox series S/X , PS3 ,android phone, PC, WIN98/8/7/ XP and other computer systems
Input DC Voltage for Charging: 5V/1A
Build-in Battery Capacity: 600mA
Dormancy Current: Less than 50uA
Input Current: 25mA-150mA
Manual Language: CH / EN / JP / ES
Package List
Wireless controller * 1
Charging cable * 1
USB receiver * 1
Manual * 1
Button Layout
1. View Button
2. LB Button
3. Left Joystick(L3)
4. D Pad
5. HOME Button
6. RT Button
7. Home Button
8. Receiver Indicator Light
9. Indicator Light
10. Menu Button
11. RB Button
12. A, B, X, Y Button
13. Right Joystick(R3)
14. Mirco Charging Port
15. LT Button
16. Reset Hole
17. USB Port
2.4 GHz Wireless Controller
This game controller has no Bluetooth function, using mature 2.4G wireless transmission technology! Superior automatic connection. The use of high-performance chips, the gamepad in the game has a better stability, high-precision 360° Rockers, the delay is almost zero, support all kinds of android devices. Support for Xbox one, Xbox series S/X , PC, tablet, TV box, smart TV, for PS3, etc. With the human body curve design, you won't feel tired even if you are addicted to the game for a long time.
Vibration Function
Vibration, mature 2.4G wireless transmission technology, no radiation, and ergonomics design,you will feel incredible comfort and hold.An ultra strong, automatic connection and connection instructions.
Multiple Connection Methods
This 2.4g controller is compatible with multi-platform games. It can be used for Xbox one/Android smart phones/tablets/TV boxes/for PS3/laptops/PC. Notice: Please make sure your phone has an OTG function. If not, the gamepad will not be compatible with your phone. Notice:Android 10 is not compatible.
Support For Xbox One and For Playstation 3
For Xbox One controller, specially designed for use with the for Xbox One console with the exact layout, ideal as an replacement or additional controller.This gamepad also support for PS3 console, please note that you need to use 2.4GHz receiver!
Powering Saving
This game console uses high-performance second-generation physical technology, high-performance 500mAh lithium battery, you only need to charge the handle for 2 hours, you can play 5 hours at full power! When you are having fun, you won't lose your enthusiasm and helplessness because the handle has no power!
High Quality Design
The gamepad is designed with 3D rocker, 360° high precision . Comfortable cross key design for more flexible and accurate steering! Ergonomic grip, Non-slip texture, matte feel, long-term grip is not tired. This controller-style joy pad provides the ultimate control for your favorite games. Positioning, sensitivity and accuracy are high.
High Sensitive Button
All controllers has passed the strict repeat keystrokes test, ensure the good performance of the buttons , provide stability and basically zero game delay. High quality pressure sensitive D-Pad, 360° without dead zone joystick, high sensibility and accuracy action button, give you the fastest gaming experience.
Stable Long Range Connection
Mature wireless 2.4GHz technology ensures a stable connection without any delay, and offers a range up to 8 meters (26.3 feet), making it possible to enjoy playing from the far side of the room
Connection Guid
1.For Xbox one
Start the Xbox one console and insert USB of the receiver to the console. The LED light
on the receiver will be on. Short press HOME Button on the controller to open the
controller. Then LED1-LED4 lights will flash to search for pairing. After they are well
connected, LED1-LED4 lights of the controller will be on and the light of the receiver
will be on, indicating that they can be used.
2.For PS3:
Start PS3 console and insert USB of the receiver to the console. The LED light on the
receiver will be on. Short press HOME Button on the controller to open the controller.
Then LED1-LED4 lights will flash to search for pairing. After they are well connected,
related indicator lights of the controller will be on and the light of the receiver will be
on, indicating that they can be used.
3.For PC:
Start PC and insert USB of the receiver to the console. The LED light on the receiver will
be on. Short press HOME Button on the controller to open the controller. Then LED1-
LED4 lights will flash to search for pairing. After they are well connected, related
indicator lights of the controller will be on and the light of the receiver will be on,
indicating that they can be used. Long press HOME Button for five seconds to switch
the X-input mode and the D-in put mode. In the X-input mode, LED1 light will be on; in
the D-input mode, LED1-LED4 lights will be on.
Auto Sleep
After it is well connected, the controller will sleep automatically if operation is done
within 5 minutes. After the controller sleeps, you can press the Home Button to power
itup and connect it with the receiver plugged on the host computer.
After it is well connected, you can close the controller by pressing L3+ R3+ HOME Button
for three seconds.
Low Voltage Alarm
If the lithium battery voltage is lower than 3. 5V0. 1V, the current channel will flash
quickly to show low voltage;
If the lithium battery voltage is lower than 3. 45V0. 1V, the controller will enter the
dormant state automatically;
Charging Indicator
Under the shutdown state of the controller, LED1-LED4 will flash slowly when th
controller is charged. After it is fully charged, the LED will be off;If the controller is charged under the connection state, the indicator light of the current channel will flash( flash slowly) , After it is fully charged, the indicator be on;
Reset
When the Controller is abnormal, you can press the small hole on the back of the controller with a small office clip to reset it.
