For SEGA Dreamcast Video Game High Definition
Newest HDMI-compatible Adapter
INTRODUCTION
The majority of modern Televisions have connectivity via HDMI-compatible and lack some of the older inputs which retro game consoles use. With the HDMI-compatible adapter cable, you can bring your old Sega Dreamcast back to life on a newer TV and relive those gaming classics, with a simple ‘PLUG AND PLAY’ solution!FEATURES
1) Video and Audio in Full Digital HDMI-compatible format with zero transmission loss!
2)Works with the majority of HDMI-compatible enabled televisions and monitors.
3)Hassle Free! Plug and Play as you go.
4)Supports all Dreamcast display modes (NTSC 480i, 480p, PAL 576i).
5) Provides advanced signal processing with great precision, colours and resolution!
6)No power adapter, no messy charging cords - Just one single HDMI-compatible cable.
SPECIFICATION
Dimensions:L: 6cm, W: 4cm, H: 1.5cm
Cable Length:24cm
Weight: 42g
Power Consumption: Below 2W
Supported Video Input Mode:Includes all the display modes of the Dreamcast console (480i, 480p, 576i)
Supported HDMI-compatible Output Mode:Outputs pure digital HDMI-compatible Video/Audio Signals
PACKAGE INCLUDES
1x HDMI-compatible Converter for Dreamcast
1x High Speed HDMITMCable
1x Quick Start Guide
Important:The HDMI-compatible adapter works by taking the absolute best available signal from the Dreamcast (VGA), and then converting it to HDMI-compatible. There are a very small number of games that were not VGA compatible (less than 20), and therefore these will not be compatible with this adapter.
DC Games that don't work with VGA:
Air Force Delta
Bangai-O
Ceasars Palace 2000: Millennium Gold Edition
ECW Anarchy Rulz
ECW Hardcore Revolution
Iron Aces
Jojo's Bizarre Adventure
The King of Fighters '99 Evolution
The King of Fighters: Dream Match 1999M
Last Blade II Heart of a Samarai
MTV Sports: Skateboarding Featuring Andy McDonald
Plasma Sword
Psychic Force 2012
The Ring: Terror's Realm Soul Fighter
WWF Attitude
HOW TO USE
1)Remove previous Dreamcast A/V cable and connect Bitfunx HDMI-compatible adapter.
2)Plug one end of your HDMI-compatible cable into the Bitfunx HDMI-compatible converter, and the other end into a free HDMI-compatible socket on your TV.
3) Power on your Dreamcast and TV. Make sure your TV’s A/V INPUT has been switched to the correct HDMI-compatible input where the Dreamcast is connected.
4) Verify that you can see the Dreamcast picture on your TV – The Bitfunx HDMI-compatible adapter LED should now be Green in colour.
5)That’s it! - Our Bitfunx HDMI-compatible adapters are ‘Plug and Play’ and very simple to use.
Please Note:The HDMI-compatible adapter does not upscale or tweak the image. If you are looking for more control over your image, then please consider the OSSC (Open Source Scan Converter)
HDMI-compatible Converter Series:
- HDMI-compatible Converter for GameCube
- HDMI-compatible Converter for PS2
- HDMI-compatible Converter for XBOX
FAQQ1: Does something need to be done with the power supply?
A1: It requires no additional power supply, just plug and play.
Q2：With VGA compared which onethe image is better?
A2: VGA is the best. Compared with AV and S-video.
Q3：Does it work with CDIimages? When using GDEMU?
A3：It works.
Q4：Can I somehow change to Dreamcast to recognize the device as VGA and as RGB?
The fact is that giving out a picture in a 480p set-top box is hard and the FPS drops to 3-5.
A4：It only support VGA signal but not RGBS signal.
Q5: What is different from such in a plastic case?
A5: The quality will be better.
Q6: Does it block the arc/cec signal like some already existing converters?
A6: Yes, It does.
Q7: Does play the games not compatible VGA like Railroad Tycoon 2?
A7: Just not support RGBS signal games.
