GBS Control RGBs /Scart /Ypbpr Signal to VGA /HDMI-compatible Upscalers / Video Converter Boards
****This product is currently in sufficient supply, you can rest assured to place an order.
If you have any questions, please contact us. Thanks.
Gbs control is an alternative firmware for Tvia Trueview5725 based upscalers / video converter boards.From the github open source project(ramapcsx2)
It has ultra-low signal delay，no synchronization loss switching 240p/480i (output runs independent from input, sync to display never drops),on demand motion adaptive deinterlacer that engages automatically and only when needed,works with almost anything: 8 bit consoles, 16/32 bit consoles, 2000s consoles, home computers, etc
Supported standards are NTSC / PAL, the EDTV and HD formats, as well as VGA from 192p to 1600x1200 (earliest DOS, home computers, PC). Sources can be connected via RGB/HV (VGA), RGBS (game consoles, SCART) or Component Video (YUV). Various variations are supported, such as the
PlayStation 2's VGA modes that run over Component cables.
1) High-definition OLED display function, control panel.
2) Optional bypass capability to, for example, transcode Component to RGB/HV in high quality.
3）Good color reproduction with auto gain and auto offset for the tripple 8 bit @ 160MHz ADC.
4) Optional control interface via web browser, utilizing the ESP8266 WiFi capabilities.
