GBSC Vido Converter GBS Control RGBS Scart YpBpr Component VGA Signal to VGA HDMI Upscalers For Retro Game Console
GBS control is an alternative firmware for Tvia Trueview5725 based upscalers / video converter boards.
Its growing list of features includes:
· very low lag.
· sharp and defined upscaling, comparing well to other -expensive- units.
· no synchronization loss switching 240p/480i (output runs independent from input, sync to display never drops).
· on demand motion adaptive deinterlacer that engages automatically and only when needed.
· works with almost anything: 8 bit consoles, 16/32 bit consoles, 2000s consoles, home computers, etc...
· lots of useful features and image enhancements.
· optional control interface via web browser, utilizing the ESP8266 WiFi capabilities.
· good color reproduction with auto gain and auto offset for the tripple 8 bit @ 160MHz ADC.
· optional bypass capability to, for example, transcode Component to RGB/HV in high quality.
Supported standards are NTSC / PAL, the EDTV and HD formats, as well as VGA from 192p to 1600x1200 (earliest DOS, home computers, PC). Sources can be connected via RGB/HV (VGA), RGBS (game consoles, SCART) or Component Video (YUV). Various variations are supported, such as the PlayStation 2's VGA modes that run over Component cables.
Instructions
When connecting to RGBS signal, please turn on RGBS syns signal.
When connecting 480p progressive RGBS signal, please turn on RGBS sync and Green sync.
When connecting component signal, please turn off RGBS sync.
When connecting VGA signal, please turn on Green sync and turn off RGBS sync.
Note: GBSC can't support AV (composite) signal input,
so please don't use AV cable to connect your console and GBSC.
Any problems if you had before placing the order, please contact us.
Connect to WIFI (gbsc) via mobile or computer.
User name; gbscontrol
password: qqqqqqqq
Web Setting Interface : Enter the IP (192.168.4.1) or URL (http://gbscontrol) in the address bar of the browser.
FAQ:
Q1: Does GBS Control support custom resolutions, custom timings at the output?
A1: It doesn’t support custom the resolutions.
Q2: Does It have the scanline function?
A2: It has scanline function.
